Product Highlights
- Stackable design supports up to 8 units with 80G stacking bandwidth
- High-speed 10G SFP+ uplinks for backbone connectivity
- Supports up to 1023 active VLANs and 16K MAC addresses
- Dual-core 600MHz CPU with 512MB RAM for efficient operations
- 1U rack-mountable design (17.5" x 11" x 1.75")
- Non-PoE configuration for standard network deployments
Overview
The Cisco Catalyst WS-C2960X-24TD-L is a 1U rack-mountable switch delivering 216 Gbps switching capacity with 24 Gigabit Ethernet ports and dual 10G SFP+ uplinks. Featuring 512MB RAM and stackable up to 8 units, it provides enterprise-grade reliability with 569,520-hour MTBF.
Technical Specifications
| Ports | 24 x 10/100/1000 + 2 x 10G SFP+ |
|---|---|
| Switching Capacity | 216 Gbps |
| Forwarding Rate | 95.2 Mpps |
| Stacking Support | 8 switches with 80G bandwidth |
| RAM | 512 MB |
| Flash Memory | 128 MB |
| VLAN Support | 1023 active / 4096 total |
| MAC Address Table | 16K entries |
| Power Consumption | 0.034KVA (32W) |
| Dimensions | 17.5 x 11.0 x 1.75 in (44.5 x 27.9 x 4.45 cm) |
| Weight | 8.9 lb (4.0 kg) |
| Operating Temperature | 23°F to 113°F (-5°C to 45°C) |
| Power Supply | 100-240V AC, 50-60Hz |
| Management Interfaces | USB Type-B, RJ-45 console |
