Product Highlights
- 32x 40/100G QSFP28 ports + 2x 10G SFP+ ports for flexible connectivity
- MACsec hardware encryption on ports 25-32 for enhanced security
- High-performance 12.84 Tbps switching capacity & 4.3 Bpps forwarding rate
- Back-to-front airflow design optimized for data center hot aisles
- Supports up to 92,000 MAC addresses for large-scale deployments
- Dual-mode operation (NX-OS and ACI) for network flexibility
Overview
The Cisco Nexus 9332C is a 1-RU spine switch designed for high-performance data center networks. Featuring 32x 40/100G QSFP28 ports with MACsec encryption on ports 25-32 and 2x 10G SFP+ ports, it delivers 12.84 Tbps switching capacity for low-latency environments. Supports both NX-OS and ACI modes with back-to-front airflow for hot aisle cabling.
Technical Specifications
| Model | N9K-C9332C |
|---|---|
| Form Factor | 1-RU |
| Port Configuration | 32x QSFP28 (40/100G), 2x SFP+ (10G) |
| Switching Capacity | 12.84 Tbps |
| Forwarding Rate | 4.3 Bpps |
| MAC Address Entries | 92,000 |
| Dimensions (H x W x D) | 1.7 x 17.3 x 22.9 in (4.4 x 43.9 x 58.1 cm) |
| Weight | 25.1 lb (11.4 kg) with PSUs/fans |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Power Consumption (Typical) | 232W AC |
| RoHS Compliance | Yes |
| End-of-Sale Date | January 30, 2024 |
