Product Highlights
- 3.6 Tbps bandwidth & 1.2 bpps forwarding rate
- 48 flexible 1/10/25/40/50/100G Ethernet ports
- 6 x 40/100G uplink ports for spine-leaf architecture
- MACsec encryption & PTP telecom profile support
- 1RU form factor for space-efficient deployments
- 32GB RAM for advanced data center operations
Overview
The Cisco Nexus 93180YC-FX3 is a 1RU fixed-configuration data center switch featuring 48 flexible-speed ports and 6 high-speed uplinks. Designed for cloud deployments, it offers 3.6 Tbps bandwidth with wire-rate security and PTP time synchronization for tel applications.
Technical Specifications
| Model | N9K-C93180YC-FX3 |
|---|---|
| Ports | 48 x 1/10/25/40/50/100-Gbps Ethernet |
| Uplink Ports | 6 x 40/100-Gbps Ethernet |
| Bandwidth | 3.6 Tbps |
| Forwarding Rate | 1.2 bpps |
| Dimensions (HxWxD) | 1.72 x 17.2 x 18 inches |
| Weight | 21 lb (9.52 kg) |
| Noise Level | 70.1-86 dBA (50-100% fan speed) |
| RAM | 32 GB |
