Product Highlights
- 24 non-PoE 10/100/1000 Ethernet ports for flexible device connectivity
- 4x 1G SFP uplink ports for high-speed network expansion
- Cisco IOS XE software for advanced security and network management
- StackWise-80 technology with 80 Gbps stacking bandwidth
- Enterprise-grade reliability with 4GB flash and 2GB DRAM
- Network Essentials software package for core feature set
Overview
The Cisco Catalyst C9200L-24T-4G-E is a scalable Layer 3 managed switch designed for enterprise deployments. Featuring 24 non-PoE Gigabit Ethernet ports and 4x1G SFP uplinks, it delivers up to 56 Gbps switching capacity with Cisco’s intent-based networking and IOS XE software.
Technical Specifications
| Model | C9200L-24T-4G-E |
|---|---|
| Switching Capacity | 56 Gbps |
| Forwarding Rate | 41.66 Mpps |
| Ethernet Ports | 24 x 10/100/1000 (non-PoE) |
| Uplink Ports | 4 x 1G SFP |
| Flash Memory | 4 GB |
| DRAM | 2 GB |
| Dimensions | 1.73 x 17.5 x 11.3 inches (44 x 445 x 288 mm) |
| Weight | 7.27 lbs (3.3 kg) |
| Software | Cisco IOS XE with Network Essentials |
| Stacking Bandwidth | 80 Gbps |
